Mixing Plant HZS60/HZS90/HZS120/HZS180/HZS240

The batching machine's storage bin is used for centralized storage and feeding of materials. The aggregate diameter measurement bin is measured by an electronic scale and then conveyed to the waiting bin by a flat belt conveyor. The waiting bin enters the main machine through a pneumatic door for stirring. Cement and fly ash are respectively conveyed to the cement weighing hopper by screw conveyors for cumulative or individual weighing. After weighing, they enter the main unit through butterfly valves for mixing. Water and additives are pumped into the metering hopper for measurement and then sent to the main unit for stirring through the pipeline pump. The well-mixed concrete is discharged through the main door opening and then enters the conveying equipment.

Advantages:

1. The entire cycle process can be controlled manually, semi-automatically or fully automatically.

2. Visual management: In the control room, the working conditions of key parts of the mixing plant can be monitored in real time through the monitoring system.

3. The standard mixing plant adopts a modular design, with reasonable installation. The equipment itself also has an outer sealing structure and can be customized according to customer requirements. It is suitable for the establishment of various standard mixing plants and is energy-saving and environmentally friendly.
